WEICHAl series diesel generator sets adopt 4105&6105 series engines produced byShanDong WEICHAI Engine Co., Ltd. ShanDong WEICHAI Engine Co. Ltd. is one joint-ventureinvested by three companies in domestic and overseas, engaging in production, trade andscientific research; 4105&6105 series engines have more fine performances including low oil
consumption, high reliability, easy to start etc.
Model | Power | Current A | Engine model | Engine | Bore | Stroke | Displacement | Consumption | Weight | Size | |
KW | KVA | ||||||||||
20GF | 22 | 20 | 39/36 | 495D6 | 29/26.5 | 95 | 115 | 3.26 | ≤258.4 | 660 | 1700×720×1080 |
24GF | 26.4 | 24 | 47/43 | 495D6 | 29/26.5 | 95 | 115 | 3.26 | ≤258.4 | 680 | 1700×720×1080 |
30GF | 30 | / | 54/ | K4100D-1 | 33/30.1 | 100 | 115 | 3.61 | ≤258.4 | 720 | 1680×720×1140 |
30GF | 33 | 30 | 59/54 | K4102D1-1 | 36/33 | 102 | 115 | 3.76 | ≤258.4 | 750 | 1610 × 600×1000 |
30GF | 33 | 30 | 59/54 | 495ZD1-4 | 39.6/36 | 95 | 115 | 3.26 | ≤251.6 | 760 | 1670 ×720 ×1140 |
40GF1 | 40 | / | 72 | K4100ZD-1 | 46/42 | 100 | 115 | 3.62 | ≤251.6 | 780 | 1670×720 ×1220 |
40GF1 | 40 | / | 72 | R4105D1 | 46/42 | 105 | 125 | 4.33 | ≤231 | 800 | 1770 ×720 ×1140 |
50GF1 | 50 | / | 90 | R4110D | 58/53 | 110 | 135 | 5.13 | ≤231 | 1035 | 1780 ×900×1360 |
50GF | 55 | 50 | 99/90 | R4105ZD1-1 | 61.6/56 | 105 | 125 | 4.33 | ≤224 | 1035 | 1780 ×900 ×1360 |
50GF | 55 | 50 | 99/90 | R6105D1-1 | 63.8/58 | 105 | 125 | 6.49 | ≤231 | 1050 | 2350 ×900 ×1600 |
64GF | 70.4 | 64 | 126/115 | R6105ZD-1 | 92.4/84 | 105 | 125 | 6.49 | ≤224 | 1200 | 2450 ×900 ×1600 |
75GF | 82.5 | 75 | 150/135 | R6105ZD-1 | 92.4/84 | 105 | 125 | 6.49 | ≤224 | 1280 | 2450 ×900 ×1600 |
90GF | 99 | 90 | 180/162 | R6105ZLD-1 | 110/100 | 105 | 125 | 6.49 | ≤224 | 1440 | 2450 ×900 ×1600 |
100GF | 110 | 100 | 198/180 | R6105AZLD-1 | 110/110 | 105 | 130 | 6.75 | ≤218 | 1440 | 2450 ×900 ×1600 |
120GF1 | 120 | / | 216 | R6105AZLD-1 | 110/110 | 105 | 130 | 6.75 | ≤218 | 1440 | 2450 ×900 ×1600 |
120GF | 132 | 120 | 238/216 | R6105IZLD7 | 145.2/132 | 105 | 135 | 7.01 | ≤218 | 1640 | 2450 ×900 ×1600 |
150GF1 | 150 | / | 270 | R6113ZLD1-1 | 170.5/155 | 113 | 125 | 7.518 | ≤218 | 2200 | 2960×1140×1850 |
